Other
Gast Catalog

1423-101Q-G625

Description

The easy to install, rugged 1423 offers oil-less operation to ensure the discharge air remains free of contamination from lubricants. They produce minimal noise or vibrations, which makes them well suited for noise sensitive environments like medical, dental and laboratory applications. In addition, these compact units offer high flow, pulse free air making them ideal for applications requiring consistent air pressure and air flow.

Specifications

Thermal Protection: NO
Operating Voltage: 220-240/380-415;208-230/460
Regulatory Approval: CE
Vanes: 4
Power Rating: 1 hp
( 0.75 kW )
Power Rating @ 50hz: 1 hp
( 0.75 kW )
Power Rating @ 60hz: 1 hp
( 0.75 kW )
Flow‎ @ 50hz: 11.5 cfm
( 19.54 m3h )
Flow @ 60hz: 13 cfm
( 22.09 m3h )
Max Pressure: 10 psi
( 0.69 bar )
Max Pressure @ 50hz: 10 psi
( 0.69 bar )
Max Pressure @ 60hz: 10 psi
( 0.69 bar )
Max Vacuum @ 50hz: 26 in-hg
( 880.46 mbar )
Max Vacuum @ 60hz‎: 26 in-hg
( 880.46 mbar )
Weight: 54.5 lbs
( 24.72 kg )
Duty Cycle: 100%
Warranty: 1 Year
Thermal Protection: NO
Operating Voltage: 220-240/380-415;208-230/460
Regulatory Approval: CE
Vanes: 4
Power Rating: 1 hp
( 0.75 kW )
Power Rating @ 50hz: 1 hp
( 0.75 kW )
Power Rating @ 60hz: 1 hp
( 0.75 kW )
Flow‎ @ 50hz: 11.5 cfm
( 19.54 m3h )
Flow @ 60hz: 13 cfm
( 22.09 m3h )
Max Pressure: 10 psi
( 0.69 bar )
Max Pressure @ 50hz: 10 psi
( 0.69 bar )
Max Pressure @ 60hz: 10 psi
( 0.69 bar )
Max Vacuum @ 50hz: 26 in-hg
( 880.46 mbar )
Max Vacuum @ 60hz‎: 26 in-hg
( 880.46 mbar )
Weight: 54.5 lbs
( 24.72 kg )
Duty Cycle: 100%
Warranty: 1 Year

Downloads

Rotary Vane Catalog
Technical Data Sheet
Operating & Maintenance Manual
Service Video
Gast Catalog

Series Options

Thermal Protection

The thermal over load protection protects motor windings from damage should the pump become stalled during operation. (AC models)

Low Maintenance

Vanes and filters are easily serviceable to extend the life of the product and maximize uptime.

FAQs
